1FW6230-0VB15-4CC2 Siemens

Simotics T Torque motor 3950Nm

no hay en stock

  • Presupuestos enviados en 1 hora
  • Los presupuestos incluyen los gastos de envío
Cargando equivalentes

Especificaciones principales

Peso y dimensiones

Detallado

SIMOTICS T TORQUE MOTOR; COMPONENT 3-PHASE SYNCHRONOUS MOTOR; INTERNAL PRECISION AND POWER COOLER; RADIAL CABLE OUTLET; DIAM 576 MM; LENGTH 210 MM; MAX TORQUE 3950 NM; MAX ROT SPEED 43 RPM; MAX CURRENT 63 ARMS; WHEN USING THE DIRECT MOTORS ON FORK HEADS FOR MACHINE TOOLS OR ROBOTS A LICENSE FOR US PATENT US5584621 AND THE CORRESPONDING WORLDWIDE PATENTS MAY BE REQUIRED

Product
Article Number (Market Facing Number) 1FW6230-0VB15-4CC2
Product Description SIMOTICS T TORQUE MOTOR; COMPONENT 3-PHASE SYNCHRONOUS MOTOR; INTERNAL PRECISION AND POWER COOLER; RADIAL CABLE OUTLET; DIAM 576 MM; LENGTH 210 MM; MAX TORQUE 3950 NM; MAX ROT SPEED 43 RPM; MAX CURRENT 63 ARMS; WHEN USING THE DIRECT MOTORS ON FORK HEADS FOR MACHINE TOOLS OR ROBOTS A LICENSE FOR US PATENT US5584621 AND THE CORRESPONDING WORLDWIDE PATENTS MAY BE REQUIRED
Product family SIMOTICS T-1FW6 built-in torque motors for SINAMICS S120
Product Lifecycle (PLM) PM300:Active Product
Price data
Price Group / Headquarter Price Group 103 / 765
List Price Show prices
Customer Price Show prices
Metal Factor ------71
Delivery information
Export Control Regulations AL : N / ECCN : N
Delivery Time 30 Day/Days
Net Weight (kg) 117,800 Kg
Product Dimensions (W x L x H) Not available
Packaging Dimension Not available
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1
Additional Product Information
EAN Not available
UPC 887621160388
Commodity Code 85030099
LKZ_FDB/ CatalogID PM21
Product Group 9701
Country of origin Germany
Compliance with the substance restrictions according to RoHS directive Given
Product class B: return restricted, please contact your Siemens partner/contact
Categorie voor terugname electronische materialen na gebruik Geen terugname verplichting
Classifications

  Version Classification
eClass 5.1 27-02-24-01
eClass 6 27-02-24-01
eClass 7.1 27-02-24-01
eClass 8 27-02-24-01
eClass 9 27-02-24-01
UNSPSC 15 26-10-11-09
