Specifiche principali
Disponibilità2.500 pz
MarchioINA
Numero articoloHK0306-TV-A INA
Conosciuto anche come
0015453610000
EAN4012802439861
CategoriaGruppo costruttivo rullino e gabbia
Peso e dimensioni
Interno (d) MM
3,00
Esterno (D) mm
6,50
Larghezza (B) MM
6,00
Interno (d) pollici
0.1181
Esterno (D) pollici
0.2559
Larghezza (B) pollici
0.2362
Peso (kg)
0.001
Proprietà del prodotto
Tenuta
Nessuna tenuta
Dati di Schaeffler (medias)
Diametro esterno del rullo di supporto (F w) mm
3,00
Larghezza (C) mm
6,00
Radial Static Load Rating C0r (N)
840
Radial Dynamic Load Rating Cr (N)
1230
Carico statico di base, radiale (C 0r)
"840.0000"
Velocità limite (n G)
"48000.0000"
Velocità limite per lubrificazione al grasso (n G Grasso)
"29000.0000"
Velocità di riferimento (n ϑr)
"57000.0000"
ECLASS number
23-05-09-05
ECLASS2 number
23-05-09-05
Descrizione dei Medias
Drawn cup needle roller bearings with open ends HK, to DIN 618/ISO 3245
Descrizione del suffisso
TVPolyamide Cage
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
