Name: GE360-DW-2RS2-B-XL INA
Brand: INA

Especificações

Disponibilidade 3 unid.
Marca INA
Número do artigo GE360-DW-2RS2-B-XL INA
Manufacturer Part Number 0174336810000
Também conhecido como GE360-DW-2RS2-B
EAN 4012802539233
Categoria Rótulas

Peso e dimensões

Interno (d) mm 360
Externo (D) mm 480
Largura (B) mm 160
Interno (d) polegadas 14.1732
Externo (D) polegadas 18.8976
Largura (B) polegadas 6.2992
Peso (kg) 86

Características do produto

Vedação 2RS2 - Fluoro Rubber Seals / High Temperature
Material de contato Aço sobre PTFE

Dados da Schaeffler (medias)

Diâmetro externo do rolamento (D) mm 480
Fator de carga radial estática C0r (N) 23800000
Largura do anel interno (B) mm 160
Fator de carga radial dinâmica Cr (N) 14300000
Número ECLASS 23-05-01-06
Número ECLASS2 23-05-01-06
Descrição do Medias Large radial spherical plain bearing, maintenance-free, sliding layer: ELGOGLIDE, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series C, sealed

Descrição do sufixo

DW Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene))
2RS2 Increased Sealing Action On Both Sides For Large Radial Spherical Plain Bearings
B Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard)
XL X-Life

Transferências e Links

Descrição do produto

The GE360-DW-2RS2-B-XL INA is a spherical plain bearing. Spherical plain bearings are two-piece plain bearings. They have no rolling elements, but consist of an inner and outer ring. The inner ring has a convex outer surface. The outer ring has a concave inner surface. This construction gives spherical plain bearings their high load carrying capacity and capacity to accommodate misalignment.

The GE360-DW-2RS2-B-XL INA has a steel-on-PTFE sliding contact which makes it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.

GE360-DW-2RS2-B-XL INA

Spherical Plain Bearing
