Especificações
Disponibilidade2 unid.
MarcaFAG
Número do artigoHCS7009-E-T-P4S-DTL FAG
Também conhecido como
0387366320000
EAN4026677595584
CategoriaRolamento de esferas de contato angular
Peso e dimensões
Interno (d) mm
45,00
Externo (D) mm
75,00
Largura (B) mm
32,00
Interno (d) polegadas
1.7717
Externo (D) polegadas
2.9528
Largura (B) polegadas
1.2598
Peso (kg)
0.5
Características do produto
Vedação
2RU - Two Seals / Non Contact Type
Tipo de gaiola
TB - gaiola reforçada de fibra
Precisão
Precisão P4S (maior que P4)
Ângulo de contato
25 graus
Pareamento
DT - arranjo em tandem, 2
Folga axial interna / pré-carga
UL - execução universal para montagem aos pares, o par de rolamentos tem uma leve pré-carga nas disposições em O ou em X
Lubrificação
Lubrificação standard
Dados da Schaeffler (medias)
Largura (b) mm
16,00
Fator de carga estática básica, radial (C 0r)
"6800.0000"
Velocidade limite para lubrificação com graxa (n G Graxa)
"30000.0000"
Número ECLASS
23-05-08-03
Número ECLASS2
23-05-08-03
Descrição do sufixo
E25° Contact Angle
TTextile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4SBoundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
The HCS7009-E-T-P4S-DTL FAG is a high-speed design hybrid spindle bearing. This bearing type has seals on both sides, and small ceramic balls. Hybrid spindle bearings can reach very high speeds with very little heat generation and wear. Even at very high speeds, a high degree of rigidity is maintained. This makes the HCS7009-E-T-P4S-DTL FAG particularly suitable for use in high-speed- or grinding spindles.
FAG spindle bearings are single-row, angular contact ball bearings that cannot be dismantled. They have solid inner and outer rings as well as ball-and-cage assemblies with solid window cages. Due to their extremely tight tolerances, they are particularly suitable for applications that require high guidance accuracy and suitability for high speeds. Spindle bearings are commonly used for main spindles in machine tools.
In addition, FAG spindle bearings are designed as universal bearings. Universal bearings with the same deviation in inner ring bore and outer diameter can be combined for use in different arrangements. For example, when the load capacity of a single bearing is insufficient, two matching bearings can be used in a tandem arrangement to support axial loads in one direction only. In order to support axial loads in both directions as well as moments, O or X arrangements are good solutions.
