HSS7011-C-T-P4S-UL FAG

Angular Contact Ball Bearing Single Row

HSS7011-C-T-P4S-UL FAG
HSS7011-C-T-P4S-UL FAG
HSS7011-C-T-P4S-UL FAG
HSS7011-C-T-P4S-UL FAG
HSS7011-C-T-P4S-UL FAG
HSS7011-C-T-P4S-UL FAG
HSS7011-C-T-P4S-UL FAG
HSS7011-C-T-P4S-UL FAG
Preço a pedido

10 unid. em stock

  • Este produto está disponível em estoque
  • Expedição até às 19:00 CEST nos dias úteis
  • Pagamento por fatura possível
  • Rastreie seu pedido com rastreamento
  • Distribuidor oficial da Schaeffler
A carregar equivalentes

Especificações

Peso e dimensões

Características do produto

Dados da Schaeffler (medias)

Descrição do sufixo

Transferências e Links

Descrição do produto

The HSS7011-C-T-P4S-UL FAG is a high-speed design spindle bearing. This bearing type has seals on both sides, and small steel balls. The bearing has an internal design with optimised friction and the balls are subjected to very low centrifugal forces. Even at very high speeds, a high degree of rigidity is maintained. This makes the HSS7011-C-T-P4S-UL FAG particularly suitable for use in high-speed- or grinding spindles.

FAG spindle bearings are single-row, angular contact ball bearings that cannot be dismantled. They have solid inner and outer rings as well as ball-and-cage assemblies with solid window cages. Due to their extremely tight tolerances, they are particularly suitable for applications that require high guidance accuracy and suitability for high speeds. Spindle bearings are commonly used for main spindles in machine tools.

In addition, FAG spindle bearings are designed as universal bearings. Universal bearings with the same deviation in inner ring bore and outer diameter can be combined for use in different arrangements. For example, when the load capacity of a single bearing is insufficient, two matching bearings can be used in a tandem arrangement to support axial loads in one direction only. In order to support axial loads in both directions as well as moments, O or X arrangements are good solutions.
