Also known as
3303ATN1
3303ATN9
3303-BD-TVH
3303-BD-XL-TVH
3303BTNG
CategoryAngular Contact Ball Bearing Double Row
Weight and Dimensions
Inner (d) MM
17
Outer (D) MM
47
Width (B) MM
22,2
Inner (d) Inch
0.6693
Outer (D) Inch
1.8504
Width (B) Inch
0.874
Weight (kg)
0.192
Product Properties
Bore
C - Cylindrical Bore
Seal
No Seal
Cage Type
P - Plastic Molded Cage
External Modification
No External Modification
Radial Internal Play
Cn Normal Internal Play
Precision
Standard Precision
Lubrication
Higher and Lower Temperature Grease
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring
Standard
Suffix description
B25º Contact Angle
TNGCage Made Of Glass-Fibre Reinforced Polyamide 66
YRLLubricant, Operating Temperature -30 ~ 120°C
NNormal Filling 35%
5Standard Single Pack. Bearings In Polythene Bags Or Hizex Film Are Placed In Individual Cardboard Boxes. The Individual Boxes Are Then Placed In A Cardboard Outer Carton And Polystrene Filled
