Name: GAKL12-PB-A INA
Brand: INA

Specifications

Availability 64 pcs
Brand INA
Item Number GAKL12-PB-A INA
Manufacturer Part Number 0065516610000
EAN 4012802521993
Category Rod End

Weight and Dimensions

Inner (d) MM 12
Outer (D) MM 33
Width (B) MM 16
Inner (d) Inch 0.4724
Outer (D) Inch 1.2992
Width (B) Inch 0.6299
Weight (kg) 0.085

Product Properties

Seal No Seal
Contact Material Steel on Bronze

Data from Schaeffler (medias)

Outside diameter bearing (D) mm 26
Radial Static Load Rating C0r (N) 20800
Width inner ring (B) mm 16
Radial Dynamic Load Rating Cr (N) 13300
ECLASS number 23-05-01-05
ECLASS2 number 23-05-01-05
Medias description Rod end with external thread, left hand thread, requiring maintenance, sliding contact surface: steel/bronze, DIN ISO 12240-4, dimension series K, type M, open design

Suffix description

PB Sliding Contact Surface Is Steel/Bronze
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

Downloads & Links

Link to manufacturer

Product description

The GAKL12-PB-A INA is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.

The GAKL12-PB-A INA has a spherical plain bearing with a steel-on-bronze sliding contact. The steel inner ring contacts the bronze surface of the outer ring. The steel-on-bronze sliding contact makes this bearing highly wear-resistant, providing low friction. However, the load capacity is slightly lower compared to spherical plain bearings with steel-on-steel sliding contacts. This bearing needs regular maintenance. Proper lubrication is required to reduce friction and prevent fouling and corrosion.

GAKL12-PB-A INA

Rod End
