Name: 239/500-MB-T52BW-C3 FAG
Brand: FAG

Specifications

Availability 1 pc
Brand FAG
Item Number 239/500-MB-T52BW-C3 FAG
Also known as 0381125900030
EAN 4026677589378
Category Spherical Roller Bearing

Weight and Dimensions

Inner (d) MM 500,00
Outer (D) MM 670,00
Width (B) MM 128,00
Inner (d) Inch 19.6850
Outer (D) Inch 26.3780
Width (B) Inch 5.0394
Weight (kg) 133

Product Properties

Bore C - Cylindrical Bore
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type M - Brass Cage
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Higher Running Acc. ISO Cl.5
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution

Data from Schaeffler (medias)

Width (b) mm 128,00
Radial Static Load Rating C0r (N) 6300000
Radial Dynamic Load Rating Cr (N) 2600000
Basic static load rating, radial (C 0r) "6300000.0000"
Limiting speed (n G) "990.0000"
Reference speed (n ϑr) "540.0000"
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearing 239..-MB, symmetric 3 ribs

Suffix description

MB Solid Brass Cage, Guidance On Inner Ring
T52BW Heightened Running Accuracy To ISO Tolerance Class 5
C3 Internal Clearance Larger Than Normal

Downloads & Links

Link to manufacturer

Product description

The 239/500-MB-T52BW-C3 FAG is a spherical roller bearing. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.

239/500-MB-T52BW-C3 FAG

Spherical roller bearing
