Specifications
Availability31 pcs
BrandSKF
Item Number32205BJ2/Q SKF
EAN7316570004014
CategoryTapered Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM
25
Outer (D) MM
52
Width (B) MM
19,25
Inner (d) Inch
0.9843
Outer (D) Inch
2.0472
Width (B) Inch
0.7579
Weight (kg)
0.186
Product Properties
Precision
Standard Precision
Suffix description
BSteeper Contact Angle Than Standard Design
J2Pressed Steel Window-Type Cage. A Figure Following The J Indicates A Different Cage Design
QOptimized Contact Geometry And Surface Finish
Product description
The 32205BJ2/Q SKF is a single-row tapered roller bearing. This bearing type gets its name from the tapered rollers between the inner and outer rings. The raceways are conical. This design allows these versatile bearings to accommodate combined loads. They support high radial and axial loads (in one direction). The greater the contact angle, the greater the axial load capacity.
The 32205BJ2/Q SKF is easy to (dis)assemble as it is a combination of a cup and a cone. The cone unit consists of an inner ring with cage and roller set. The cup is the outer ring. Single-row tapered roller bearings have an open design. Because of the internal construction, they must be mounted in mirror-image arrangement together with a second tapered roller bearing. Paired bearing sets can also be applied in X, O, or tandem arrangements.
