Specifications

• Availability 264 pcs
• Brand INA
• Item Number 3800-2RS INA
• Also known as 0009954360000

• EAN 4012802126075
• Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

• Inner (d) MM 10,00
• Outer (D) MM 19,00
• Width (B) MM 7,00
• Inner (d) Inch 0.3937
• Outer (D) Inch 0.7480
• Width (B) Inch 0.2756
• Weight (kg) 0.006

Product Properties

• Bore C - Cylindrical Bore
• Seal 2RS - Rubber Seal on Two Sides
• Cage Type P - Plastic Molded Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Split Inner ring / Outer ring Standard

Data from Schaeffler (medias)

• Width (b) mm 7,00
• Radial Static Load Rating C0r (N) 1370
• Radial Dynamic Load Rating Cr (N) 2080
• Basic static load rating, radial (C 0r) "1370.0000"
• Limiting speed (n G) "21100.0000"
• ECLASS number 23-05-08-03
• ECLASS2 number 23-05-08-03
• Medias description Angular contact ball bearings 38..-B-2RS, Double row design, lip seals on both sides, contact angle a = 25°
