Specifications

• Availability 230 pcs
• Brand INA
• Item Number 3805-2Z INA
• Manufacturer Part Number (MPN) 0009964320000
• EAN 4012802484779
• Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

• Inner (d) MM 25
• Outer (D) MM 37
• Width (B) MM 10
• Inner (d) Inch 0.9843
• Outer (D) Inch 1.4567
• Width (B) Inch 0.3937
• Weight (kg) 0.027

Product Properties

• Bore C - Cylindrical Bore
• Seal ZZ/2Z - Steel Seal on Two Sides
• Cage Type P - Plastic Molded Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Split Inner ring / Outer ring Standard

Data from Schaeffler (medias)

• Width (b) mm 10
• Radial Static Load Rating C0r (N) 5500
• Radial Dynamic Load Rating Cr (N) 5900
• Limiting speed (n G) 15300
• Reference speed (n ϑr) 10300
• ECLASS number 23-05-08-03
• ECLASS2 number 23-05-08-03
• Medias description Angular contact ball bearing 38..-B-2RZ-TVH, double row, 1 inner ring
