Specifications

• Availability 0 pcs
• Brand INA
• Item Number 3903-2RS INA
• Also known as 0038276580000

• EAN 4012802470710
• Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

• Inner (d) MM 17,00
• Outer (D) MM 30,00
• Width (B) MM 10,00
• Inner (d) Inch 0.6693
• Outer (D) Inch 1.1811
• Width (B) Inch 0.3937
• Weight (kg) 0.022

Product Properties

• Bore C - Cylindrical Bore
• Seal 2RS - Rubber Seal on Two Sides
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Split Inner ring / Outer ring Standard

Data from Schaeffler (medias)

• Width (b) mm 10,00
• Radial Static Load Rating C0r (N) 4100
• Radial Dynamic Load Rating Cr (N) 5200
• Basic static load rating, radial (C 0r) "4100.0000"
• Limiting speed (n G) "13300.0000"
• ECLASS number 23-05-08-03
• ECLASS2 number 23-05-08-03
• Medias description Angular contact ball bearing 39..-B-2RSR-TVH, double row, 1 inner ring
