4307-BB-TVH FAG

Specifications

• Availability 35 pcs
• Brand FAG
• Item Number 4307-BB-TVH FAG
• Also known as 0219434350000

• EAN 4026677966032
• Category Deep Groove Ball Bearing Double Row

Weight and Dimensions

• Inner (d) MM 35
• Outer (D) MM 80
• Width (B) MM 31
• Inner (d) Inch 1.378
• Outer (D) Inch 3.1496
• Width (B) Inch 1.2205
• Weight (kg) 0.758

Product Properties

• Bore C - Cylindrical Bore
• Seal No Seal
• Cage Type P - Plastic Molded Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Radial Static Load Rating C0r (N) 40500
• Radial Dynamic Load Rating Cr (N) 58000
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearings 43..-BB, main dimensions to DIN 625-3, double row
