Also known as
6001 2RS
6001-2HRS
6001-2RS1
6001-2RSH
6001-2RSR
EAN4064327029300
CategoryDeep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM
12
Outer (D) MM
28
Width (B) MM
8
Inner (d) Inch
0.4724
Outer (D) Inch
1.1024
Width (B) Inch
0.315
Weight (kg)
0.0206
Product Properties
Bore
C - Cylindrical Bore
Seal
2RH - High Speed Low Friction Seal on Two Sides
Cage Type
S - Steel or Standard Cage
External Modification
No External Modification
Radial Internal Play
Cn Normal Internal Play
Precision
Standard Precision
Lubrication
Standard Lubrication
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Special Treatment
No Special Treatment
Data from Schaeffler (medias)
Radial Static Load Rating C0r (N)
2370
Radial Dynamic Load Rating Cr (N)
5900
ECLASS number
23-05-08-01
ECLASS2 number
23-05-08-01
Medias description
Deep groove ball bearings 60..-C-2HRS, modified internal construction (Generation C), main dimensions to DIN 625-1, lip seals on both sides
Suffix description
CDeep Groove Ball Bearings Of Generation C, Modified Internal Construction
2HRSLip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal
