Specifications

• Availability 1,240 pcs
• Brand FAG
• Item Number 6002-C-2Z FAG
• Manufacturer Part Number 0593717140000
• Also known as 6002-2Z

• EAN 4012802363357
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 15
• Outer (D) MM 32
• Width (B) MM 9
• Inner (d) Inch 0.5906
• Outer (D) Inch 1.2598
• Width (B) Inch 0.3543
• Weight (kg) 0.031

Product Properties

• Bore C - Cylindrical Bore
• Seal ZZ/2Z - Steel Seal on Two Sides
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 9
• Radial Static Load Rating C0r (N) 2850
• Radial Dynamic Load Rating Cr (N) 6000
• Limiting speed (n G) 31500
• Reference speed (n ϑr) 23200
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearings 60..-C-2Z, modified internal construction (Generation C), main dimensions to DIN 625-1, gap seals on both sides
