Specifications

• Availability 119 pcs
• Brand FAG
• Item Number 6004-C-2HRS FAG
• Manufacturer Part Number 0949816800000
• Also known as 6004-2RS
  6004-2RS1
  6004-2RSH
  6004-2RSR

• EAN 4012802384758
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 20
• Outer (D) MM 42
• Width (B) MM 12
• Inner (d) Inch 0.7874
• Outer (D) Inch 1.6535
• Width (B) Inch 0.4724
• Weight (kg) 0.0676

Product Properties

• Bore C - Cylindrical Bore
• Seal 2RH - High Speed Low Friction Seal on Two Sides
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 12
• Radial Static Load Rating C0r (N) 5000
• Radial Dynamic Load Rating Cr (N) 10600
• Limiting speed (n G) 15300
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearings 60..-C-2HRS, modified internal construction (Generation C), main dimensions to DIN 625-1, lip seals on both sides
