Loading equivalents
Specifications
Availability2,603 pcs
BrandFAG
Item Number6200-C-2HRS FAG
Manufacturer Part Number0621487960000
Also known as
6200-2RS1
6200-2RSH
6200-2RSR
6200-C-2HRS#E
EAN4012802383416
CategoryDeep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM
10
Outer (D) MM
30
Width (B) MM
9
Inner (d) Inch
0.3937
Outer (D) Inch
1.1811
Width (B) Inch
0.3543
Weight (kg)
0.0317
Product Properties
Bore
C - Cylindrical Bore
Seal
2RH - High Speed Low Friction Seal on Two Sides
Cage Type
S - Steel or Standard Cage
External Modification
No External Modification
Radial Internal Play
Cn Normal Internal Play
Precision
Standard Precision
Lubrication
Standard Lubrication
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Special Treatment
No Special Treatment
Data from Schaeffler (medias)
Width (b) mm
9
Radial Static Load Rating C0r (N)
2600
Radial Dynamic Load Rating Cr (N)
6600
Limiting speed (n G)
26000
ECLASS number
23-05-08-01
ECLASS2 number
23-05-08-01
Medias description
Deep groove ball bearing 62..-C-2HRS, single row, cf. DIN 625-1
Suffix description
CDeep Groove Ball Bearings Of Generation C, Modified Internal Construction
2HRSLip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal
