6209-2RS1/C3 SKF

Rubber seal (2 sides) Higher (internal) clearance 45x85x19mm

37 pcs in stock

  • This product is available from stock
  • usp_shipment_times
  • Payment by invoice possible
  • Track your order with track & trace
Loading equivalents


Weight and Dimensions

Product Properties

Suffix description

Product description

The 6209-2RS1/C3 SKF is a deep groove ball bearing with a single row design. Deep groove ball bearings have a straight forward design, are robust in operation and are easy to maintain. Deep groove ball bearings reduce rotational friction and support both radial and axial loads.

The 6209-2RS1/C3 SKF is suitable for high speeds and can operate with low noise.

The dimensions of the 6209-2RS1/C3 SKF are: Bore (or inner diameter) 45mm, Outer diameter 85mm and Width (or thickness) 19mm.

6200 serie
The 6209-2RS1/C3 SKF is part of the popular 6200 serie which contain extra light ball bearings and are perfect for limited space applications.The 6200 serie is used in a wide range of industrial processes as well as DIY applications like: skateboards, inline skates, bicycles, washing and drying machines.

The 2RS1 suffix indicates that the bearing has a rubber seal on both sides. If necessary the seals can easily removed if the application requires only 1 seal. The rubber seal protects the ingress of moisture, dust or other dirt. The bearings are filled with a high quality grease and are lubricated for life.

Internal play
The C3 in the product name means that this bearing has a higher (internal) clearance than normal. The C3 clearance is most frequently used for this type of bearings. The extra internal clearance allows expansion due to high speeds or temperatures.

About SKF
SKF is the most renowned producer of bearings worldwide. SKF stands for outstanding quality and has been a forerunner in the production of bearings and related items for years. By buying a SKF bearing you are sure to buy top quality.
