Specifications

• Availability 9 pcs
• Brand FAG
• Item Number 6320-Z FAG
• Also known as 0191117460000

• EAN 4012801281409
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM 100,00
• Outer (D) MM 215,00
• Width (B) MM 47,00
• Inner (d) Inch 3.9370
• Outer (D) Inch 8.4646
• Width (B) Inch 1.8504
• Weight (kg) 7.395

Product Properties

• Bore C - Cylindrical Bore
• Seal Z - Steel Seal on One Side
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Data from Schaeffler (medias)

• Width (b) mm 47,00
• Radial Static Load Rating C0r (N) 137000
• Radial Dynamic Load Rating Cr (N) 177000
• Basic static load rating, radial (C 0r) "137000.0000"
• Limiting speed (n G) "4250.0000"
• Reference speed (n ϑr) "4600.0000"
• ECLASS number 23-05-08-01
• ECLASS2 number 23-05-08-01
• Medias description Deep groove ball bearing 63..-Z, single row, cf. DIN 625-1
