Specifications
Availability76 pcs
BrandNSK
Item Number6336MRC4P5BX26U3U303 NSK
Also known as
6336FY C4
6336M P54
6336M.C4
6336M/C4C02S0
6336M/P54
6336-MB-C4-T52BE-S0
6336-M-C4
6336-M-P54
6336-M-P5-C4
CategoryDeep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM
180
Outer (D) MM
380
Width (B) MM
75
Inner (d) Inch
7.0866
Outer (D) Inch
14.9606
Width (B) Inch
2.9528
Weight (kg)
41
Product Properties
Bore
C - Cylindrical Bore
Seal
No Seal
Cage Type
M - Brass Cage
External Modification
No External Modification
Radial Internal Play
C4 Internal Play (Higher than C3)
Precision
Inner Accuracy (1/4 RBEC.1)
Lubrication
Standard Lubrication
Heat Stabilization
S0 - Temperatures up to 150 °C
Special Treatment
No Special Treatment
Suffix description
MRRoller Guided Machined Brass Cage
C4Bearing Internal Clearance Greater Than C3
P5BInner Ring With P5 Running Accuracy, Mark High And Low Points Of Eccentricity On Face Of Rings
X26Dimensionally Stabilized For Operating Temperature Of 150°C Max
U3Special Quality Control Specification
U303The Code U303 In The Article Number Of An NSK Bearing Shows That It Was Specially Developed And Produced For Use In Wind Power Technology. These Wind Turbine Bearings Are Made From Premium, High-Purity Bearing Steels And Special Steels Used Exclusively By NSK. They Are Also Assembled In Separate Production Areas And Subject To Special Packaging Regulations, Which Prevent Contamination
