Specifications
Availability3 pcs
BrandNSK
Item Number70BNR10HTYNDBBELP4 NSK
CategoryAngular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM
70
Outer (D) MM
110
Width (B) MM
80
Inner (d) Inch
2.7559
Outer (D) Inch
4.3307
Width (B) Inch
3.1496
Weight (kg)
2.44
Product Properties
Seal
No Seal
Cage Type
P - Plastic Molded Cage
Precision
H4 - Hybrid / Ceramic Balls / P4
Contact Angle
18 degrees
Pairing
QBC - O-arrangement, 4
Axial Internal Clearance / Preload
GX - Extra Light Preload
Lubrication
Standard Lubrication
Suffix description
HRings Made From Bearing Steel (SUJ2), Rolling Elements Made From Ceramic (SI3N4)
TYNThis Special Design Allows The Bearing To Have Lower Friction And Lower Noise. The Temperature Rise Of The Bearing With A TYN Cage Is Lower Than That With A Phenolic Cage At A Rotational Speed Lower Than 1.4 Million DmN* ("Dm
NPitch Circle Diameter Of Rolling Elements (mm)" x "Speed" (Min-1"))
DBBQuadruplex Set Of Bearings In A Back-To-Back Configuration <<>>
ELExtra Light Preload
P4Dimensional & Running Accuracy To ISO Tolerance Class 4 (More Accurate Than P5)-ABEC.7
