Also known as
TKR8066
VKBA1403
VKBA1439
VKBA1447
VKBA1486
VKBA3416
VKBA895
VKBA896
CategoryAngular Contact Ball Bearing Double Row
Weight and Dimensions
Inner (d) MM
37
Outer (D) MM
72
Width (B) MM
37
Inner (d) Inch
1.4567
Outer (D) Inch
2.8346
Width (B) Inch
1.4567
Weight (kg)
0.636
Product Properties
Bore
C - Cylindrical Bore
Seal
ZZ/2Z - Steel Seal on Two Sides
Cage Type
S - Steel or Standard Cage
External Modification
No External Modification
Radial Internal Play
Cn Normal Internal Play
Precision
Standard Precision
Lubrication
Standard Lubrication
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring
Split inner ring
Suffix description
ADouble Row Angular Contact Ball Bearing Without Filling Slots
DUnknown
Product description
The BAH-0012AD SKF is a double-row angular contact ball bearing with solid inner- and outer rings. The design of this bearing type resembles two single-row angular contact ball bearings in O-arrangement but is slightly narrower. Double-row angular contact ball bearings can support high radial forces and axial forces in both directions. The greater the contact angle, the greater the axial load capacity of the bearing.
The BAH-0012AD SKF has a split inner ring. This bearing type combines a large number of balls with a large contact angle. This design makes the bearing suitable for higher axial loads in both directions. Bearings with split inner rings generally have a tighter fit than bearings with single-piece inner rings.
