Also known as
CFE24-PP-Y
CR1.1/2XBCE
CRSBCE24
CS48LWX
CategoryCam Follower
Weight and Dimensions
Inner (d) MM
0,00
Outer (D) MM
38,10
Width (B) MM
0,00
Inner (d) Inch
0.0000
Outer (D) Inch
1.5000
Width (B) Inch
0.0000
Weight (kg)
0.24
Product Properties
Seal
2L - LS-seal at Both Sides
Excenterring
E - Excenterring with Inbus Mount
Running Surface
Standard
Suffix description
SCam Follower, Camrol, Sealed Version
BCam Follower, Camrol, Hexagonal Hole Replaces Screwdriver Slot In Flange End Of Stem
Product description
The CCFE1.1/2SB McGill is a cam follower with needle rollers. These rolling elements combine high load capacity with a compact design. Cam followers are designed for use with various types of tracks. Thanks to a thick-walled outer ring, they can withstand high radial loads. Instead of an inner ring, they feature a solid, threaded stud, enabling easy mounting. Axial loads due to alignment errors or misalignment can be absorbed in both directions. They are not mounted in a housing bore, but a flat (counter) track provides support.
The CCFE1.1/2SB McGill is equipped with a cage that prevents the rolling elements from coming into contact with each other. This design allows for a controlled movement of the rolling elements. There is lower friction compared to full complement cam followers, allowing for higher rotational speeds and less heat generation. Common applications of cam followers include conveyor systems, linear guidance systems, and cam mechanisms.
