Specifications

• Availability 4 pcs
• Brand INA
• Item Number DKLFA2080-2RS INA
• Manufacturer Part Number 0025079430000
• EAN 4012802440355
• Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

• Inner (d) MM 20
• Outer (D) MM 52
• Width (B) MM 35
• Inner (d) Inch 0.7874
• Outer (D) Inch 2.0472
• Width (B) Inch 1.378
• Weight (kg) 0.7

Product Properties

• Bore C - Cylindrical Bore
• Seal 2RS - Rubber Seal on Two Sides
• Cage Type S - Steel or Standard Cage
• External Modification F - Flange
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Split Inner ring / Outer ring Split inner ring

Data from Schaeffler (medias)

• Width (b) mm 35
• Axial Static Load Rating C0a (N) 47000
• Axial Dynamic Load Rating Ca (N) 26000
• Limiting speed for grease lubrication (n G Grease) 5000
• Thermally permissible speed (n ϑ) 2200
• ECLASS number 23-05-10-02
• ECLASS2 number 23-05-10-02
• Medias description Angular contact ball bearing units DKLFA..-2RS, double direction, for screw mounting, lip seals on both sides, with flattened flange
