Specifications
Availability51 pcs
BrandINA
Item NumberE30-XL-KRR-B INA
Manufacturer Part Number0008112620000
Also known as
E30-KRR-B
EAN4012802782998
CategoryBearings for Housings
Weight and Dimensions
Inner (d) MM
30
Inner (d) Inch
1.1811
Weight (kg)
0.38
Product Properties
Seal
2RS - Rubber Seal on Two Sides
Lubrication
Standard Lubrication
Special Treatment
No Special Treatment
Data from Schaeffler (medias)
Outside diameter (D SP) mm
62
Width (b) mm
36,5
Locking collar total width (B 1) mm
48,5
Radial Static Load Rating C0r (N)
11300
Radial Dynamic Load Rating Cr (N)
20700
ECLASS number
23-05-08-02
ECLASS2 number
23-05-08-02
Medias description
Radial insert ball bearings E..-KRR-B, spherical outer ring, location by eccentric locking collar, R seals on both sides
Suffix description
XLX-Life
KRRLip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
