Loading equivalents
Specifications
Availability31 pcs
BrandINA
Item NumberGAKL16-PB INA
Manufacturer Part Number0066333660000
Also known as
SALKAC16M
EAN4012802524079
CategoryRod End
Weight and Dimensions
Inner (d) MM
16
Outer (D) MM
43
Width (B) MM
21
Inner (d) Inch
0.6299
Outer (D) Inch
1.6929
Width (B) Inch
0.8268
Weight (kg)
0.19
Product Properties
Seal
No Seal
Contact Material
Steel on Bronze
Data from Schaeffler (medias)
Outside diameter bearing (D) mm
32
Radial Static Load Rating C0r (N)
45300
Width inner ring (B) mm
21
Radial Dynamic Load Rating Cr (N)
21400
ECLASS number
23-05-01-05
ECLASS2 number
23-05-01-05
Medias description
Rod end with external thread, left hand thread, requiring maintenance, sliding contact surface: steel/bronze, DIN ISO 12240-4, dimension series K, type M, open design
The GAKL16-PB INA is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.
The GAKL16-PB INA has a spherical plain bearing with a steel-on-bronze sliding contact. The steel inner ring contacts the bronze surface of the outer ring. The steel-on-bronze sliding contact makes this bearing highly wear-resistant, providing low friction. However, the load capacity is slightly lower compared to spherical plain bearings with steel-on-steel sliding contacts. This bearing needs regular maintenance. Proper lubrication is required to reduce friction and prevent fouling and corrosion.
