Loading equivalents
Specifications
Availability8 pcs
BrandINA
Item NumberGAKSL6-PS INA
Manufacturer Part Number0598986660000
EAN4012802545463
CategoryRod End
Weight and Dimensions
Inner (d) MM
6
Outer (D) MM
21
Width (B) MM
9
Inner (d) Inch
0.2362
Outer (D) Inch
0.8268
Width (B) Inch
0.3543
Weight (kg)
0.02
Product Properties
Seal
No Seal
Contact Material
Steel on PTFE
Data from Schaeffler (medias)
Outside diameter bearing (D) mm
16
Outer eye diameter (d 2) mm
21
Radial Static Load Rating C0r (N)
2500
Width inner ring (B) mm
9
Radial Dynamic Load Rating Cr (N)
7650
Total length external thread rod (l 2) mm
46,5
ECLASS number
23-05-01-05
ECLASS2 number
23-05-01-05
Medias description
Corrosion-resistant rod end, with external thread, maintenance-free, sliding layer: PTFE film, DIN ISO 12240-4, dimension series K, type F, open design
The GAKSL6-PS INA is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.
The GAKSL6-PS INA has a spherical plain bearing with a steel-on-PTFE sliding contact, making it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.
