Specifications
Availability40 pcs
BrandINA
Item NumberGAL15-DO INA
Manufacturer Part Number0066337140000
Also known as
GAL15ES
SAL15ES
EAN4012802524598
CategoryRod End
Weight and Dimensions
Inner (d) MM
15
Outer (D) MM
41
Width (B) MM
12
Inner (d) Inch
0.5906
Outer (D) Inch
1.6142
Width (B) Inch
0.4724
Weight (kg)
0.12
Product Properties
Seal
No Seal
Contact Material
Steel on Steel
Data from Schaeffler (medias)
Outside diameter bearing (D) mm
26
Radial Static Load Rating C0r (N)
41600
Width inner ring (B) mm
12
Radial Dynamic Load Rating Cr (N)
16900
ECLASS number
23-05-01-05
ECLASS2 number
23-05-01-05
Medias description
Rod end with external thread, left hand thread, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-4, dimension series E, type M, open
The GAL15-DO INA is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.
The GAL15-DO INA has a spherical plain bearing with a steel-on-steel sliding contact. Both the outer and inner rings of this bearing are made of steel. Bearings with steel-on-steel sliding contacts are wear-resistant and have a high load carrying capacity. This bearing type requires regular maintenance. Proper lubrication is required to reduce friction and prevent fouling and corrosion.
