Loading equivalents
Specifications
Availability14 pcs
BrandNeutral
Item NumberGEG50ES-2RS Neutral
Also known as
GEH50ES-2RS
CategorySpherical Plain Bearing
Weight and Dimensions
Inner (d) MM
50
Outer (D) MM
90
Width (B) MM
56
Inner (d) Inch
1.9685
Outer (D) Inch
3.5433
Width (B) Inch
2.2047
Weight (kg)
1.4
Product Properties
Seal
2RS - Rubber Seal on Two Sides
Contact Material
Steel on Steel
Suffix description
ESSliding Contact Surface Steel/Steel, Split Outer Ring With Lubrication Holes
2RSLip Seals On Both Sides
Product description
The GEG50ES-2RS Neutral is a spherical plain bearing. Spherical plain bearings are two-piece plain bearings. They have no rolling elements, but consist of an inner and outer ring. The inner ring has a convex outer surface. The outer ring has a concave inner surface. This construction gives spherical plain bearings their high load carrying capacity and capacity to accommodate misalignment.
The GEG50ES-2RS Neutral has a steel-on-steel sliding contact. Both the outer and inner rings of this bearing are made of steel. Bearings with steel-on-steel sliding contacts are wear-resistant and have a high load carrying capacity. This bearing type requires regular maintenance. Proper lubrication is required to reduce friction and prevent fouling and corrosion.
