Name: GIHRK60-DO-A INA
Brand: INA

Specifications

Availability 9 pcs
Brand INA
Item Number GIHRK60-DO-A INA
Manufacturer Part Number 0066347880000
Also known as SIR60ES
TAPR60U
EAN 4012802525731
Category Rod End

Weight and Dimensions

Inner (d) MM 60
Outer (D) MM 132
Width (B) MM 44
Inner (d) Inch 2.3622
Outer (D) Inch 5.1969
Width (B) Inch 1.7323
Weight (kg) 6.2

Product Properties

Seal No Seal
Contact Material Steel on Steel

Data from Schaeffler (medias)

Radial Clearance (G r) 0,043 - 0,12
Outside diameter bearing (D) mm 90
Radial Static Load Rating C0r (N) 327000
Radial Dynamic Load Rating Cr (N) 245000
ECLASS number 23-05-01-05
ECLASS2 number 23-05-01-05
Medias description Hydraulic rod end, with thread clamping device, right hand thread, requiring maintenance, sliding contact surface: steel/steel, open design

Suffix description

DO Sliding Contact Surface Steel/Steel
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

Downloads & Links

Link to manufacturer

Product description

The GIHRK60-DO-A INA is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.

The GIHRK60-DO-A INA has a spherical plain bearing with a steel-on-steel sliding contact. Both the outer and inner rings of this bearing are made of steel. Bearings with steel-on-steel sliding contacts are wear-resistant and have a high load carrying capacity. This bearing type requires regular maintenance. Proper lubrication is required to reduce friction and prevent fouling and corrosion.

GIHRK60-DO-A INA

Rod End
