Specifications
Availability12 pcs
BrandINA
Item NumberGIKL30-PW INA
Manufacturer Part Number0066349150000
EAN4012802525861
CategoryRod End
Weight and Dimensions
Inner (d) MM
30
Outer (D) MM
70
Width (B) MM
37
Inner (d) Inch
1.1811
Outer (D) Inch
2.7559
Width (B) Inch
1.4567
Weight (kg)
1.1
Product Properties
Seal
No Seal
Contact Material
Steel on PTFE
Data from Schaeffler (medias)
Outside diameter bearing (D) mm
55
Radial Static Load Rating C0r (N)
95900
Width inner ring (B) mm
37
Radial Dynamic Load Rating Cr (N)
114000
ECLASS number
23-05-01-05
ECLASS2 number
23-05-01-05
Medias description
Rod end with internal thread, left hand thread maintenance-free, sliding layer: PTFE film brass outer ring, DIN ISO 12240-4, dimension series K, type F, open design
Suffix description
PWSliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film
The GIKL30-PW INA is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.
The GIKL30-PW INA has a spherical plain bearing with a steel-on-PTFE sliding contact, making it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.
