Name: GIKR6-PW-A INA
Brand: INA

Specifications

Availability 65 pcs
Brand INA
Item Number GIKR6-PW-A INA
Manufacturer Part Number 0066350910000
EAN 4012802526202
Category Rod End

Weight and Dimensions

Inner (d) MM 6
Outer (D) MM 20
Width (B) MM 9
Inner (d) Inch 0.2362
Outer (D) Inch 0.7874
Width (B) Inch 0.3543
Weight (kg) 0.0256

Product Properties

Seal No Seal
Contact Material Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm 16
Radial Static Load Rating C0r (N) 7990
Width inner ring (B) mm 9
Radial Dynamic Load Rating Cr (N) 7750
ECLASS number 23-05-01-05
ECLASS2 number 23-05-01-05
Medias description Rod end with internal thread, right hand thread, maintenance-free, sliding layer: PTFE film brass outer ring, DIN ISO 12240-4, dimension series K, type F, open design

Suffix description

PW Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

Downloads & Links

Link to manufacturer

Product description

The GIKR6-PW-A INA is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.

The GIKR6-PW-A INA has a spherical plain bearing with a steel-on-PTFE sliding contact, making it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.

GIKR6-PW-A INA

Rod End
