Specifications
Availability111 pcs
BrandINA
Item NumberGYE70-XL-KRR-B INA
Manufacturer Part Number0009358320000
Also known as
GYE70-KRR-B
YAR214-2F
EAN4012802804850
CategoryBearings for Housings
Weight and Dimensions
Inner (d) MM
70
Outer (D) MM
125
Width (B) MM
69,9
Inner (d) Inch
2.7559
Outer (D) Inch
4.9213
Width (B) Inch
2.752
Weight (kg)
1.85
Product Properties
Seal
2F - Standard Seal for Y-bearings
Lubrication
Standard Lubrication
Special Treatment
No Special Treatment
Data from Schaeffler (medias)
Outside diameter (D SP) mm
125
Width (b) mm
74,6
Radial Static Load Rating C0r (N)
44000
Radial Dynamic Load Rating Cr (N)
66000
ECLASS number
23-05-08-02
ECLASS2 number
23-05-08-02
Medias description
Radial insert ball bearings GYE..-KRR-B, spherical outer ring, location by grub screws, R seals on both sides
Suffix description
XLX-Life
KRRLip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
