Specifications
Availability2 pcs
BrandSKF
Item NumberHM220149/110/Q SKF
Also known as
BT1-0828
HM220149/HM220110
HM220149/HM220110/Q
HM220149-99401
VKHB2717MY
EAN7316570862423
CategoryTapered Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM
99,97
Outer (D) MM
156,97
Width (B) MM
42,00
Inner (d) Inch
3.9360
Outer (D) Inch
6.1801
Width (B) Inch
1.6535
Weight (kg)
2.75
Product Properties
Precision
Standard Precision
Suffix description
QTQ-Line Execution. (100% Interchangeable With Basic Designation)
Product description
The HM220149/110/Q SKF is a single-row tapered roller bearing. This bearing type gets its name from the tapered rollers between the inner and outer rings. The raceways are conical. This design allows these versatile bearings to accommodate combined loads. They support high radial and axial loads (in one direction). The greater the contact angle, the greater the axial load capacity.
The HM220149/110/Q SKF is easy to (dis)assemble as it is a combination of a cup and a cone. The cone unit consists of an inner ring with cage and roller set. The cup is the outer ring. Single-row tapered roller bearings have an open design. Because of the internal construction, they must be mounted in mirror-image arrangement together with a second tapered roller bearing. Paired bearing sets can also be applied in X, O, or tandem arrangements.
