Also known as
HM516449C/410
HM516449C/HM516410
SET422
EAN0053893661544
CategoryTapered Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM
82,55
Outer (D) MM
133,35
Width (B) MM
39,69
Inner (d) Inch
3.25
Outer (D) Inch
5.25
Width (B) Inch
1.5625
Weight (kg)
2.206
Product Properties
Precision
Standard Precision
Suffix description
C(Cup/Outer Race) Dimensionally Different From Basic Part Number (Non-Interchangeable)
99401Inspection Code. (Can Be Used As Standard)
Product description
The HM516449C-99401 Timken is a single-row tapered roller bearing. This bearing type gets its name from the tapered rollers between the inner and outer rings. The raceways are conical. This design allows these versatile bearings to accommodate combined loads. They support high radial and axial loads (in one direction). The greater the contact angle, the greater the axial load capacity.
The HM516449C-99401 Timken is easy to (dis)assemble as it is a combination of a cup and a cone. The cone unit consists of an inner ring with cage and roller set. The cup is the outer ring. Single-row tapered roller bearings have an open design. Because of the internal construction, they must be mounted in mirror-image arrangement together with a second tapered roller bearing. Paired bearing sets can also be applied in X, O, or tandem arrangements.
