Also known as
LM503349/310/Q
LM503349/LM503310
LM503349/LM503310/QCL7C
EAN7316571065922
CategoryTapered Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM
45,99
Outer (D) MM
74,98
Width (B) MM
18,00
Inner (d) Inch
1.8105
Outer (D) Inch
2.9518
Width (B) Inch
0.7087
Weight (kg)
0.3
Product Properties
Precision
A1 - Special Quality for Pignons
Suffix description
QTQ-Line Execution. (100% Interchangeable With Basic Designation)
CL7CHigh-Performance Design For Pinion Bearing Arrangements
Product description
The LM503349/310/QCL7C SKF is a single-row tapered roller bearing. This bearing type gets its name from the tapered rollers between the inner and outer rings. The raceways are conical. This design allows these versatile bearings to accommodate combined loads. They support high radial and axial loads (in one direction). The greater the contact angle, the greater the axial load capacity.
The LM503349/310/QCL7C SKF is easy to (dis)assemble as it is a combination of a cup and a cone. The cone unit consists of an inner ring with cage and roller set. The cup is the outer ring. Single-row tapered roller bearings have an open design. Because of the internal construction, they must be mounted in mirror-image arrangement together with a second tapered roller bearing. Paired bearing sets can also be applied in X, O, or tandem arrangements.
