Specifications
Availability16 pcs
BrandTimken
Item NumberLM78349/LM78310A Timken
Also known as
LM78349/310A
SET106-900SA
EAN0053893658827
CategoryTapered Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM
34,99
Outer (D) MM
61,97
Width (B) MM
18,00
Inner (d) Inch
1.3775
Outer (D) Inch
2.4399
Width (B) Inch
0.7087
Weight (kg)
0.19
Product Properties
Precision
Standard Precision
Suffix description
A(Cup/Outer Race) Different Outer Diameter / Radius / Width From Basic Part Number
Product description
The LM78349/LM78310A Timken is a single-row tapered roller bearing. This bearing type gets its name from the tapered rollers between the inner and outer rings. The raceways are conical. This design allows these versatile bearings to accommodate combined loads. They support high radial and axial loads (in one direction). The greater the contact angle, the greater the axial load capacity.
The LM78349/LM78310A Timken is easy to (dis)assemble as it is a combination of a cup and a cone. The cone unit consists of an inner ring with cage and roller set. The cup is the outer ring. Single-row tapered roller bearings have an open design. Because of the internal construction, they must be mounted in mirror-image arrangement together with a second tapered roller bearing. Paired bearing sets can also be applied in X, O, or tandem arrangements.
