Specifications
Availability8 pcs
BrandFAG
Item NumberN1011-D-TVP-SP-XL FAG
Manufacturer Part Number0929544800000
Also known as
N1011-D-TVP-SP
EAN4054371090494
CategoryCylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM
55
Outer (D) MM
90
Width (B) MM
18
Inner (d) Inch
2.1654
Outer (D) Inch
3.5433
Width (B) Inch
0.7087
Weight (kg)
0.439
Product Properties
Bore
C - Cylindrical Bore
Seal
No Seal
Cage Type
P - Plastic Molded Cage
External Modification
No External Modification
Radial Internal Play
Cn Normal Internal Play
Precision
SP - Precision Higher than P4S
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm
18
Radial Static Load Rating C0r (N)
48500
Radial Dynamic Load Rating Cr (N)
48000
Fatigue load limit, radial (C ur)
7900
Limiting speed for grease lubrication (n G Grease)
12600
Limiting speed for oil lubrication (n G Oil)
14800
ECLASS number
23-05-09-01
ECLASS2 number
23-05-09-01
Medias description
Cylindrical roller bearing N10..-D-TVP-SP-XL, with cage, single row, non-locating bearing, 0 ribs on outer ring (smooth), 2 ribs on inner ring, type N
Suffix description
DBearings With A Modified Internal Construction And The Suffix D Do Not Have A Lubrication Hole Or Lubrication Groove As Standard
TVPMoulded Polyamide Window-Type Cage, Rolling Element Riding
SPSuper Precision Specification, Tolerance Class SP, Radial Clearance C1
The N1011-D-TVP-SP-XL FAG is a single-row cylindrical roller bearing with cage. This bearing consists of a solid inner and outer ring with cylindrical rollers in a cage. This cage prevents contact between the cylinder rollers, so this bearing type can support higher speeds than full-complement cylinder roller bearings. Also, single-row cylindrical roller bearings with cages are very rigid and they can take high radial forces. As the inner and outer rings of these bearings can be easily disassembled, they are very easy to install. Applications of single-row cylindrical roller bearings include gearboxes, agricultural machinery, pumps, compressors, and electric motors.
The N1011-D-TVP-SP-XL FAG is a single-row cylinder bearing with N design. The inner ring has two rigid ribs, while the outer ring has none. As a result, N bearings are only capable of supporting radial forces. This bearing type is commonly used as a floating bearing. Floating bearings allow axial displacement of the shaft relative to the housing in both directions. This is necessary in applications where the shaft material shrinks or expands due to temperature changes (thermal expansion).
The N1011-D-TVP-SP-XL FAG is an X-life type cylindrical roller bearing. X-life bearings provide better performance than normal cylindrical roller bearings due to a special internal construction. Contact surfaces, steel grade and rolling bodies are of a higher quality. X-life bearings combine a higher load capacity with a longer service life. The bearings generate less heat and allow for higher speeds. Finally, X-life bearings allow for longer maintenance intervals compared to normal cylindrical roller bearings.
