Home Cylindrical Roller Bearing Single Row NJ207E.TVP2 FAG


Cylindrical Roller Bearing 35x72x17mm

not in stock

Loading equivalents

Product properties


Category information NJ207E.TVP2 FAG

Single row cylindrical roller bearings with cage, like the NJ207E.TVP2 FAG, are units comprising solid inner and outer rings together with cylindrical roller and cage assemblies.

The outer rings have rigid ribs on both sides or no ribs, the inner rings have one or two rigid ribs or are designed without ribs. The cage prevents the cylindrical rollers from coming into contact with each other during rolling.

The cage type bearings are very rigid, can support high radial loads and, due to the cage, are suitable for higher speeds than the full complement designs.

The bearings are separable and are therefore easier to fit and dismantle. Both bearing rings can be given a tight fit by this process.

Applications of NJ207E.TVP2 FAG

Product specifications NJ207E.TVP2 FAG

Bearings with the suffix E have a higher capacity roller set and are thus designed for very high load carrying capacity.

NJ207E.TVP2 FAG is a semi-locating bearing

Cylindrical roller bearings NJ are semi-locating bearings. Semi-locating bearings can support not only high radial forces but also axial forces in one direction and can therefore guide shafts axially in one direction. They act as non-locating bearings in the opposite direction. The bearings have two ribs on the outer ring and one rib on the inner ring.

Axial displacement: The outer and inner ring can be axially displaced relative to each other in one direction only by the value “s”.

Bearings with L-section ring: Non-locating bearings NJ can be combined with an L-section ring HJ to form a locating bearing unit. This design has two ribs on the outer ring, one rib on the inner ring and an L-section ring for the ribless side of the inner ring. The L-section rings suitable for the bearings are indicated in the dimension tables. The bearing and L-section ring must be ordered separately.

L-section rings: L-section rings are advantageous where, under high loads, the seating surface of the inner ring in NUP bearings with a loose rib washer is too small to provide a sufficiently high bearing seat. In some applications, they make it easier to fit and dismantle the bearings.

Sealing of NJ207E.TVP2 FAG

The bearings are supplied without seals.

Lubrication of NJ207E.TVP2 FAG

They can be lubricated from the end faces using grease or oil.

Operating temperature of NJ207E.TVP2 FAG

Bearings with a plastic cage (suffix TVP2) are suitable up to +120 °C; the operating life is heavily dependent on the lubricant used.

Cage of NJ207E.TVP2 FAG

Cylindrical roller bearings with the suffix TVP2 have a cage made from glass fibre reinforced polyamide PA66.

Check the chemical resistance of polyamide to synthetic greases and lubricants with EP additives.

Aged oil and additives in the oil can impair the operating life of plastic cages at high temperatures. The oil change intervals must be observed.

Suffix info NJ207E.TVP2 FAG
