Specifications
Availability1 pc
BrandFAG
Item NumberNU1088-TB-M1 FAG
Manufacturer Part Number0815116200000
EAN4054366897053
CategoryCylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM
440
Outer (D) MM
650
Width (B) MM
94
Inner (d) Inch
17.3228
Outer (D) Inch
25.5906
Width (B) Inch
3.7008
Weight (kg)
105
Product Properties
Bore
C - Cylindrical Bore
Seal
No Seal
Cage Type
M - Brass Cage
External Modification
No External Modification
Radial Internal Play
Cn Normal Internal Play
Precision
Standard Precision
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm
94
Radial Static Load Rating C0r (N)
2750000
Radial Dynamic Load Rating Cr (N)
1560000
Limiting speed (n G)
1600
Reference speed (n ϑr)
860
ECLASS number
23-05-09-01
ECLASS2 number
23-05-09-01
Medias description
Cylindrical roller bearing NU20..-E-XL-M1, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU
Suffix description
TBThe Rollers Have A Special Crowning On The Side Surface. Is Not Depending On The Cage Design. The Result Is A Better Lubrication In Between Roller And Rim
The NU1088-TB-M1 FAG is a single-row cylindrical roller bearing with cage. This bearing consists of a solid inner and outer ring with cylindrical rollers in a cage. This cage prevents contact between the cylinder rollers, so this bearing type can support higher speeds than full-complement cylinder roller bearings. Also, single-row cylindrical roller bearings with cages are very rigid and they can take high radial forces. As the inner and outer rings of these bearings can be easily disassembled, they are very easy to install. Applications of single-row cylindrical roller bearings include gearboxes, agricultural machinery, pumps, compressors, and electric motors.
The NU1088-TB-M1 FAG is a single-row cylindrical bearing with NU design. The outer ring of this bearing has two rigid ribs, while the inner ring has none. As a result, NU bearings are only capable of supporting radial forces. This bearing type is commonly used as a floating bearing. Floating bearings allow axial displacement of the shaft relative to the housing in both directions. This is necessary in applications where the shaft material shrinks or expands due to temperature changes (thermal expansion). NU bearings can also be used as support bearings by combining them with HJ angle rings (available separately). Support bearings can support radial forces and also axial forces in a single direction.
