Loading equivalents
Specifications
Availability1 pc
BrandFAG
Item NumberNU210-E-XL-M1-F1-J20AA-R65-80NA FAG
Manufacturer Part Number0390426004033
EAN4012802115581
CategoryCylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM
50
Outer (D) MM
90
Width (B) MM
20
Inner (d) Inch
1.9685
Outer (D) Inch
3.5433
Width (B) Inch
0.7874
Weight (kg)
0.532
Product Properties
Bore
C - Cylindrical Bore
Seal
No Seal
Cage Type
M - Brass Cage
External Modification
No External Modification
Radial Internal Play
Cn Normal Internal Play
Precision
Bearings for Traction Motors
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm
20
Basic static load rating, radial (C 0r)
69000
Limiting speed (n G)
14500
Reference speed (n ϑr)
6600
Suffix description
EIncreased Load Capacity
XLX-Life
M1Solid Brass Cage, Two Piece, Roller Guided
F1FAG Manufacturing And Inspection Specification For Cylindrical Roller Bearings In Traction Motors Which Considers, Among Others, The Requirements According To Din 43283 "Cylindrical Roller Bearings For Electric Traction"
