Also known as
NU219ECMAN/C3B20
NU219-E-N-MPAX-F59-C3
EAN4054371422769
CategoryCylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM
95
Outer (D) MM
170
Width (B) MM
32
Inner (d) Inch
3.7402
Outer (D) Inch
6.6929
Width (B) Inch
1.2598
Weight (kg)
3.11
Product Properties
Bore
C - Cylindrical Bore
Seal
No Seal
Cage Type
MA - Brass Cage, Centered on Outer Ring
External Modification
N - Snap Ring Groove in Outer Ring
Radial Internal Play
C3 Internal Play (Higher than Cn)
Precision
A2 - Reduced Width Tolerance
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Suffix description
EIncreased Load Capacity
XLX-Life
NSnap Ring Groove In The Outer Ring
MPAXRib-Guided Single-Piece Solid Brass Cage Is A Further Development Of FAG Cage Types MPA And MP1A And Will Replace These Types Successively. It Has Greater Durability With Regard To Shock Loads And Vibrations Than It's Predecessors And It's Especially Well Suited For Applications Involving High Loads
F59Replaced By
H68Bearing And Bearing Parts For Voith Getriebe KG, Heidenheim; For Special Cage Design, Width Tolerance, Radial Runout And Bearing Clearance See Specifications
