Specifications
Availability1 pc
BrandFAG
Item NumberNU248-E-TB-MCA FAG
Manufacturer Part Number3016528480000
EAN4064328283275
CategoryCylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM
240
Outer (D) MM
440
Width (B) MM
72
Inner (d) Inch
9.4488
Outer (D) Inch
17.3228
Width (B) Inch
2.8346
Weight (kg)
51.8
Product Properties
Bore
C - Cylindrical Bore
Seal
No Seal
Cage Type
MA - Brass Cage, Centered on Outer Ring
External Modification
No External Modification
Radial Internal Play
Cn Normal Internal Play
Precision
Standard Precision
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Suffix description
EIncreased Load Capacity
TBThe Rollers Have A Special Crowning On The Side Surface. Is Not Depending On The Cage Design. The Result Is A Better Lubrication In Between Roller And Rim
MCASolid Brass Cage, Single-Piece, Guided On Outer Ring
