Specifications
Availability86 pcs
BrandINA
Item NumberRAE20-XL-NPP-NR INA
Manufacturer Part Number0009731220000
Also known as
RAE20-NPP-NR
EAN4012802820973
CategoryBearings for Housings
Weight and Dimensions
Inner (d) MM
20
Outer (D) MM
47
Width (B) MM
31
Inner (d) Inch
0.7874
Outer (D) Inch
1.8504
Width (B) Inch
1.2205
Weight (kg)
0.17
Product Properties
Seal
2F - Standard Seal for Y-bearings
Lubrication
Non-Regreaseable
Special Treatment
No Special Treatment
Data from Schaeffler (medias)
Width (b) mm
21,4
Locking collar total width (B 1) mm
31
Radial Static Load Rating C0r (N)
6600
Radial Dynamic Load Rating Cr (N)
13600
ECLASS number
23-05-08-02
ECLASS2 number
23-05-08-02
Medias description
Radial insert ball bearings RAE..-NPP-NR, cylindrical outer ring, location by eccentric locking collar, slots in outer ring, P seals on both sides
Suffix description
XLX-Life
NPPLip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded)
NRSlot And Snap Ring For Radial Insert Ball Bearings With Cylindrical Outer Ring
