Loading equivalents
Specifications
Availability49 pcs
BrandINA
Item NumberRSL183013-A-XL INA
Manufacturer Part Number0506229860000
Also known as
RSL183013-A
EAN4012802420531
CategoryCylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM
65
Outer (D) MM
93,1
Width (B) MM
26
Inner (d) Inch
2.5591
Outer (D) Inch
3.6654
Width (B) Inch
1.0236
Weight (kg)
0.492
Product Properties
Bore
C - Cylindrical Bore
Seal
No Seal
Cage Type
FC - Full Complement, No Cage
External Modification
No External Modification
Radial Internal Play
Cn Normal Internal Play
Precision
Standard Precision
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
E w mm
93,09
Width (b) mm
26
Radial Static Load Rating C0r (N)
157000
Radial Dynamic Load Rating Cr (N)
130000
Limiting speed (n G)
4600
ECLASS number
23-05-09-01
ECLASS2 number
23-05-09-01
Medias description
Cylindrical roller bearing RSL1830..-XL, full complement roller set, single row, non-locating bearing, no outer ring, 2 ribs on inner ring, type RSL18
Suffix description
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
