Specifications
Availability10 pcs
BrandINA
Item NumberRSL185014-A-2S INA
Manufacturer Part Number0014425200954
EAN4012802725513
CategoryCylindrical Roller Bearing Multi Row
Weight and Dimensions
Inner (d) MM
70
Outer (D) MM
100,28
Width (B) MM
108
Inner (d) Inch
2.7559
Outer (D) Inch
3.948
Width (B) Inch
4.252
Weight (kg)
2.24
Product Properties
Bore
C - Cylindrical Bore
Seal
No Seal
Cage Type
FC - Full Complement, No Cage
External Modification
No External Modification
Radial Internal Play
Cn Normal Internal Play
Precision
Set of Two for Side-by-Side
Heat Stabilization
No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
ECLASS number
23-05-09-01
ECLASS2 number
23-05-09-01
Suffix description
AThe Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
2SBearings Matched In Set Of Two For Side-By-Side Mounting, Tolerance Is Matched Based On The Inner, Outer And Clearance Of The Bearing
