Specifications
Availability2 pcs
BrandSKF
Item NumberS7006CE/HCP4ADBA SKF
EAN7316575984168
CategoryAngular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM
30
Outer (D) MM
55
Width (B) MM
26
Inner (d) Inch
1.1811
Outer (D) Inch
2.1654
Width (B) Inch
1.0236
Weight (kg)
0.22
Product Properties
Seal
2RL - Low Friction NBR-seal
Cage Type
TB - Hard Fiber Cage
Precision
H4 - Hybrid / Ceramic Balls / P4
Contact Angle
15° Contact High Speed Design
Pairing
DB - O-arrangement, 2
Axial Internal Clearance / Preload
GA - Light Preload
Lubrication
Standard Lubrication
Suffix description
CE15° Contact Angle And (E) Small Size Balls
HCBearing Or Bearing Components Of Ceramic
P4ADimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4
DBATwo Single Row Deep Groove Ball Bearings, Single Row Angular Contact Ball Bearings Or Single Row Tapered Roller Bearings Matched For Mounting In A Back-To-Back Arrangement, Light Preload
