Specifications
Availability28 pcs
BrandSKF
Item NumberSA8E SKF
Also known as
GAR8-DO
TFE8MK
EAN7316577002501
CategoryRod End
Weight and Dimensions
Inner (d) MM
8
Outer (D) MM
25
Width (B) MM
8
Inner (d) Inch
0.315
Outer (D) Inch
0.9843
Width (B) Inch
0.315
Weight (kg)
0.0306
Product Properties
Seal
No Seal
Contact Material
Steel on Steel
Suffix description
ESteel-On-Steel, Annular Groove And Lubrication Holes In Both Inner And Outer Rings
Product description
The SA8E SKF is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.
The SA8E SKF has a spherical plain bearing with a steel-on-steel sliding contact. Both the outer and inner rings of this bearing are made of steel. Bearings with steel-on-steel sliding contacts are wear-resistant and have a high load carrying capacity. This bearing type requires regular maintenance. Proper lubrication is required to reduce friction and prevent fouling and corrosion.
