Specifications

• Availability 4 pcs
• Brand INA
• Item Number ZKLFA0850-2RS INA
• Manufacturer Part Number 0001304780000
• EAN 4012802424768
• Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

• Inner (d) MM 8
• Outer (D) MM 32
• Width (B) MM 20
• Inner (d) Inch 0.315
• Outer (D) Inch 1.2598
• Width (B) Inch 0.7874
• Weight (kg) 0.17

Product Properties

• Bore C - Cylindrical Bore
• Seal 2RS - Rubber Seal on Two Sides
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal Play Cn Normal Internal Play
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Split Inner ring / Outer ring Split inner ring

Data from Schaeffler (medias)

• Width (b) mm 20
• Axial Static Load Rating C0a (N) 16300
• Axial Dynamic Load Rating Ca (N) 12500
• Limiting speed for grease lubrication (n G Grease) 12100
• Thermally permissible speed (n ϑ) 5100
• ECLASS number 23-05-10-02
• ECLASS2 number 23-05-10-02
• Medias description Angular contact ball bearing units ZKLFA..-2RS, double direction, for screw mounting, lip seals on both sides, with flattened flange
