Specifications
Availability5 pcs
BrandRossi
Item NumberHC471B423046060B5 Rossi
CategoryStainless Steel Motors
Weight and Dimensions
Weight (kg)
13.5
Product Properties
Rated power (kW)
0.37
Speed at 50Hz (rpm)
1500 / 4-Poles
Frequency
60 Hz
Energy efficiency
Not applicable
Mounting
B5 (outer flange)
Brake
No Brake
IP Class
IP68
Explosion safety (Atex)
No protection
IEC Framesize
71
Detailed Product Properties
Voltage
All other voltages
IEC Framesize
71
Shaft diameter (mm)
14
Housing material
Stainless steel
AC/DC
AC
Standard
IEC
Shaft height IEC in JDE
071
Shaft length (mm)
30
Shaft key width (mm)
5
Shaft key length (mm)
22
Thread shaft bore
M5
Shaft height, B3 mounted (mm)
71
Width foot holes, B3 mounted (mm)
112
Length foot holes, B3 mounted (mm)
90
Diameter foot holes (mm)
7
Outer diameter flange B5/V1/B35/V3 (mm)
160
Spigot B5/V1/B35/V3 (mm)
110
Pitch circle diameter B5/V1/B35/V3 (mm)
130
Number of flange holes
4
Diameter flange holes B5/V1/B35/V3 (mm)
10
Pitch circle diameter B14/B34/V18/V19 (mm)
85
Thread flange holes B14/B34/V18/V19
M6
Outer diameter flange B14/B34/V18/V19 (mm)
105
Spigot B14/B34/V18/V19 (mm)
70
Product description
The HC471B423046060B5 Rossi is part of the HyCLEAN range. These extremely solid stainless steel motors are very suitable for use in food, chemical and pharmaceutical industries where moisture resistance and hygiene are of the utmost importance. In these environments motors come into contact with humidity, water jets, chemicals and oil.
The HC4's housing is made of AISI 316 grade stainless steel. An important feature of this material is its excellent corrosion resistance. In addition, the interior is able to withstand rough conditions as well. The rotor has an anti-corrosion coating and the windings are encased in an extra hard two-component resin.
This HyCLEAN motor lives up to its name as it is very easy to clean thanks to a highly streamlined design. The scratch-resistant design of the HC471B423046060B5 with IP68 rating makes sanitisation a breeze. Dirt doesn't get a chance to adhere to the smooth surface and the lack of a fan and cooling fins prevents the spread of bacteria.
Rossi is a renowned Italian company which pays a lot of attention to technical innovations and where quality and reliability are held in high regard. In addition, within its wide range of products there is always a tailor-made solution to be found. Rossi products are used in a wide selection of diverse industries including the metal, gas and oil industry and offshore marine applications.
